Brand: Hubbell
Hubbell FXS-22C Tumbler Switch
Part Number # FXS-22C
SKU # 2303115
$700.48 / Each
Hubbell FXS-22C Key Features
Brand: Hubbell
Part Number # FXS-22C
SKU #2303115
Actuator: Lever
Amperage Rating: 20, 20 A
Contact Rating: 20 A at 120/277 VAC
Dimensions: 6.63 in L x 6 in W x 4.38 in H
NEMA Rating: NEMA 3CD/7CD/9EFG
Number of Poles: 2
Phase: 1
Series: FXS
Type: Dead End
Voltage Rating: 120/277, 120/277 VAC
Color: Gray
Country of origin: CN, US
Material: Cast Aluminum
Manufacturer Name: Hubbell
UNSPSC: 39122211
UPC: 00783936195100
$700.48 / Each
Hubbell FXS-22C Tumbler Switch
Brand: Hubbell
Part Number: FXS-22C
Killark Tumbler Switch, Dead End, Series: FXS, 120/277 VAC, 20 A, 2 Pole, 20 A at 120/277 VAC Contact, 1 Phase, Lever Actuator, NEMA 3CD/7CD/9EFG, Cast Aluminum, Gray, 6.63 in L x 6 in W x 4.38 in H Dimensions
Additional Description: KILL-FXS-22C TUMBL SWITCH 3/4"" 2P20A DEAD
Catalog Description: FXS Series - Aluminum Dead-End 2-Pole Tumbler Switch Unit - Factory Sealed - Hub Size 3/4 Inch - 20A
FXS-22C Application
For making, breaking or changing connections in an electric circuitFXS-22C Includes
Box, Cover, Switch and GFI UnitsFXS-22C Item Features
- 1 hp at 120 VAC/2 hp at 240 VAC power rating
- Test and reset push buttons are provided on cover assembly
- Exterior gasket provides NEMA 3 weatherproof protection
- Ground boss for grounding in the splice box
- Captive cover bolts are made from stainless steel
- 3/4 in hub size
- Eliminates external sealing requirements
- Includes new GFI to meet latest UL943 GFCI standards revisions
- 60 Hz frequency
- Class A insulation
- 4 to 6 mA trip setting
- Lower installation cost
- Color coded wiring with more wiring space for easier field installation
- Lockout accessory available must be factory installed
- Operating shaft in both push buttons and selector switches are stainless steel
FXS-22C Standards
UL File No. E80595 Listed|CSA File No. LR61895 CertifiedSKU #2303115Part Number #FXS-22CUNSPSC39122211UPC00783936195100
