Hubbell HBL2731S Locking Plug
Part Number # HBL2731S
SKU # 220681
$61.71 / Each
$79.70/Each
Hubbell HBL2731S Key Features
Brand: Hubbell
Part Number # HBL2731S
SKU #220681
Amperage Rating: 30, 30 A
Cord Diameter: 0.35 to 1.15, 0.35 to 1.15 in
Dimensions: 2.33 in Dia x 4.21 in L, 2.33 x 2.33 x 4.21, 2.33 x 2.33 x 4.21 in
Enclosure: IP20
Horsepower: 10, 10 hp
NEMA Rating: L16-30P, NEMA L16-30R
Number of Poles: 3
Number of Wires: 4
Temperature Rating (Degrees F): -40 to 75, -40 to 75 deg C
Terminal Type: Screw
Type: 3-Phase Grounding Male Standard, 3-Phase Grounding Male Standard Cord Mount
Voltage Rating: 480, 480 VAC
Color: Black/White
Country of origin: PR, US
Material: Brass/Clear Polycarbonate/Composite/Nylon/Polybutylene Terephthalate, Nylon
Manufacturer Name: Hubbell
UNSPSC: 39121402
UPC: 00783585234861
$61.71 / Each
$79.70/Each
Hubbell HBL2731S Locking Plug
Brand: Hubbell
Part Number: HBL2731S
Wiring Device-Kellems Twist-Lock Safety-Shroud Locking Plug, 3-Phase Grounding Male Standard Cord Mount, 480 VAC, 30 A, 10 hp, 3 Pole, 4 Wires, L16-30P NEMA Rating, IP20 Enclosure, 0.35 to 1.15 in Diameter Cord, -40 to 75 deg C, Screw Terminal, Nylon, Black/White, 2.33 x 2.33 x 4.21 in
Additional Description: HUBW-HBL2731S LKG S/SHRD PLUG, 30A 3P 480V, L16-30P
Catalog Description: Locking Devices, Twist-Lock®, Safety-Shroud®, Male Plug, 30A 3-Phase 480V AC, 3-Pole 4-Wire Grounding, NEMA L16- 30P, Screw Terminal, Black and White Nylon Body, White PBT Shroud.
HBL2731S Application
Dry Locations, Power Connection and Indoor ApplicationsHBL2731S Item Features
- Impact resistant shroud protects blades against bending and breaking
- Ribbed nylon housing provides a secure grip and impact and chemical resistance
- Superior cord grip design protects terminations from excess strain
- Integral dust shield protects wiring chamber from dust or contaminants
- https://youtu.be/1DnPJu3QNw0
HBL2731S Standards
RoHS Compliant|CSA C22.2 No. 42/0.6|UL94HB Flammability Rating|Federal Specification W-C-596|UL 94/498SKU #220681Part Number #HBL2731SUNSPSC39121402UPC00783585234861
