Brand: Hubbell
Hubbell XS-52C Tumbler Switch
Image Disclaimers Message
Brand: Hubbell
Hubbell XS-52C Tumbler Switch
Brand: Hubbell
Hubbell XS-52C Tumbler Switch
Part #:XS-52C
SKU #: 2233091
$366.52/EA
Key Features
Part #:XS-52C
SKU #: 2233091
Brand: Hubbell
Actuator: Lever
Amperage Rating: 20, 20 A
Contact Rating: 20 A at 120/277 VAC
Dimensions: 5-7/8 in H x 3 in W x 4-1/16 in D
NEMA Rating: NEMA 7/9
$366.52/EA
- 1 hp at 120 VAC/2 hp at 240 VAC power rating
- Lever is connected to a threaded stainless steel shaft which passes through the cover
- Front lever rotary operated switch assemblies with standard provisions for padlocking in either ON or OFF position
- Standard provisions for padlocking in either ON or OFF position
- 3/4 in hub size
- DP action
- Aluminum factory sealed dead-end splice box enclosure type
Specifications
Brand: Hubbell
Actuator: Lever
Amperage Rating: 20, 20 A
Contact Rating: 20 A at 120/277 VAC
Dimensions: 5-7/8 in H x 3 in W x 4-1/16 in D
NEMA Rating: NEMA 7/9
Number of Poles: 2
Phase: 1
Series: XS Series
Type: Feed Through
Voltage Rating: 120/277, 120/277 VAC
Color: Gray
Material: Aluminum
UNSPSC: 39122211
UPC: 00783936930565
Hubbell XS-52C Tumbler Switch
Killark Tumbler Switch, Feed Through, Series: XS Series, 120/277 VAC, 20 A, 2 Pole, 20 A at 120/277 VAC Contact, 1 Phase, Lever Actuator, NEMA 7/9, Aluminum, Gray, 5-7/8 in H x 3 in W x 4-1/16 in D Dimensions
Additional Description: KILL-XS-52C CLI 20A 2P 3/4"" FEED-THRU (CS)
Catalog Description: XS Series - Aluminum Feed-Thru 2-Pole Tumbler Switch Unit - Hub Size 3/4 Inch - 20A
